BirdDog X4 Ultra Ultimate Wireless Camera with NDI HX3 and AI Tracking (White) (3-Pack) Bundle
Couldn't load pickup availability
Product highlights
Product highlights
In the box
In the box
Free standard shipping
Free standard shipping
*Orders placed before 1 PM EST Mon - Thur will ship the same day. Orders placed beyond these hours will be shipped the next business day. Exclusions apply. See shipping policy
Free Local Pickup
Free Local Pickup
Please call for store stock availability. Requests made before 2:30 PM EST can be available for next-day pickup. Learn more
BirdDog X4 Ultra Ultimate Wireless Camera with NDI HX3 and AI Tracking (White)
The BirdDog X4 Ultra is the ultimate solution for live production professionals, combining exceptional image quality with unmatched flexibility. Designed to go wherever you go, the X4 Ultra eliminates the need for cables with its built-in battery, lasting up to 6 hours, and cutting-edge Wi-Fi 6 for ultra-fast, reliable streaming. Whether you're capturing a dynamic event or shooting in hard-to-reach places, the X4 Ultra ensures you never miss a moment. With support for multiple professional connections like NDI and HX3, 3G-SDI, HDMI, USB-C, RTMP, and RTSP, it’s ready for any production environment. Plus, its advanced AI tracking ensures seamless, automated camera movement for precise control. Whether you're working solo or managing up to 4 cameras wirelessly, the X4 Ultra offers intuitive management through the BirdUI platform, providing easy access to all camera functions, even from remote locations. For superior visibility on set, the built-in HALO Tally system keeps your talent and crew engaged, making it clear which camera is live at all times. Get more from every shoot with the BirdDog X4 Ultra - a flexible, versatile tool designed to meet the demands of today’s fast-paced production environments.
BirdDog KBD PTZ Controller with Integrated HD Screen Display (Black)
The BirdDog KBD Controller is the ideal tool for PTZ camera operators, designed with a rugged, ergonomic build and a large screen displaying up to four cameras at once. The streamlined menu provides direct access to essentials like camera pairing, while its built-in tally display integrates with mixers like TriCaster or vMix, showing the live camera right on the keyboard. With tactile feedback for camera switching, it’s intuitive and comfortable for extended use. The BirdDog KBD adapts to any setup with NDI, VISCA, ONVIF, RS-232, and RS-422 connectivity, and reflects BirdDog’s commitment to sustainability with its ocean-bound plastic construction. Packed with enhanced features, including improved access, configuration, and joystick calibration, it’s a powerful, affordable solution shaped by user feedback for greater control, comfort, and reliability.
All Day Comfort
KBD is crafted for those who rely on precision and ease in their workflow. With a rugged, ergonomic design, it's built for comfort, featuring a hand-rest area and tactile controls for all-day use.
Expanded Screen, Instant Camera Control
With a large screen that lets you monitor up to four cameras simultaneously or focus on one in full screen, seamless pairing, and effortless switching are just a button press away. The improved tactile feedback ensures smooth, intuitive transitions at your fingertips.
Camera Setting Sync
An industry-first feature: effortlessly tune one camera to your exact preferences and instantly copy those settings to another camera of the same model (BirdDog X series function). Simplifying camera setup and elevating your production to the next level.
Direct Access to Key Functions
No more endless menu diving! KBD brings you straight to the essentials. With its streamlined layout, operators can access camera pairing, switching, and configuration in seconds. It's all there, clear and accessible, thanks to user feedback that’s shaped a truly user-friendly experience.
Super-Fine Control Mode
When it's time to fine-tune, just shift the camera joystick into 'fine-tune' mode, increasing the sensitivity of the joystick by 10x, making reframing shots on air more artistic flair than nail-biting scare.
Built-In Tally Borders
Pairing and switching between cameras is just a single press away, with tactile buttons providing instant feedback under your finger for smooth, intuitive transitions.
Imaging
| Sensor Type | CMOS |
| Camera Format | CMOS |
| Sensor Size | 1/1.8 inch |
| Megapixels | 8.42 |
Exposure Control
| Shutter Speed | 1/10000 to 1 Second |
Video
| Video Resolution | 4K |
| Live Streaming | SRT/RTSP/RTMP/NDI|HX3/NDI|HX2 3840 x 2160 at 30p, 29.97p, 25p, 60p, 59.94p, 59.94i, 50p |
| Recording Modes | External Mode: HDMI / RJ45 / USB UHD 4K (3840 x 2160) at 25/29.97/30.00/50/59.94/60.00 fps HD (1920 x 1080p) at 25/29.97/30.00/50/59.94/60.00 fps HD (1920 x 1080i) at 50/59.94 fps HD (1280 x 720) at 59.94/60.00 fps SDI/BNC HD (1920 x 1080p) at 25/29.97/30.00/50/59.94/60.00 fps HD (1920 x 1080i) at 50/59.94 fps HD (1280 x 720) at 59.94/60.00 fps |
Physical
| Configuration | Bundle 1 |
| Color | White |
| Maximum Tilt Angle | Tilt: 120° (-30 to 90°) at 1.7 to 60°/s |
Lens
| Optical Zoom | 20x |
| Zoom | 20x |
BirdDog X4 Ultra: Ultimate Wireless Camera with NDI HX3 and AI Tracking
| Color | White |
| Image Sensor | Sony 1/1.8 inch CMOS |
| Optical Zoom | 20x |
| Video Outputs | 3G-SDI, HDMI, USB-C, NDI HX3, RTMP, RTSP |
| Battery Life | Up to 6 hours |
| Wi-Fi | Wi-Fi 6 (2x2 MIMO) |
| Control Protocols | NDI HX3, VISCA, RS-232, ONVIF |
| Audio Input | 3.5mm TRS Line/Mic input |
| Pan/Tilt Range | Plus-minus 170 degrees pan, minus 30 to 90 degrees tilt |
| Speed | Pan (1.7 to 80 degrees per second), Tilt (1.7 to 60 degrees per second) |
| Presets | Up to 255 |
| Weight | 2.19 kg (4.83 lbs) |
| Dimensions | 140.2 x 188.9 x 203.2 mm |
| Power Supply | DC 12V, PoE IEEE 802.3at |
BirdDog KBD PTZ Controller with Integrated HD Screen Display
| Color | Black |
Camera Control
| PTZ Control | VISCA-IP, NDI, ONVIF, PELCO-P, PELCO-D |
| Fine PTZ Control | VISCA-IP, NDI |
| Focus Control | Auto Focus, Manual Focus buttons |
| Auto Exposure | Direct Button |
| Manual Exposure | Toggle Dial adjustment Brightness/Shutter/Gain/Iris |
| Auto White Balance | Direct Button |
| Manual White Balance | Toggle Dial adjustment R-Gain, B-Gain, Color Temperature |
| Auto Focus | Direct Button |
| Manual Focus | Direct Button (Near/Far) |
| BLC (Backlight Compensation) | Direct Button |
| Zoom Ring on Joystick | Yes (Enable/Disable) |
| Programmable Trigger on Joystick | Adjustable, One-Push Focus, AI Tracking, One-Push AWB |
| AI Camera Mode Control | Camera Dependent, supported |
| Copy/Paste Camera Settings | Supported on selected BirdDog Cameras (VISCA-IP, NDI) |
Camera Access
| Max. Cameras support | 255 |
| Direct Camera access keys | 6 |
| Direct Preset access keys | 10 |
| Max Preset support | 255 per camera |
| OSD Camera Menu | Menu button and interaction with joystick |
Display
| Display Resolution | 1280x720 |
| Multiview IP Video | Supported, NDI HX (Proxy), RTSP (max. 30 fps) |
| Full-Screen IP Video | Supported, NDI HX (Proxy), RTSP (max. 30 fps) |
| IP Video CODEC support | h.264, h.265 |
| Tally Borders | Selectable, Multiview, and full screen mode |
| On-Screen Menu | Fully configurable |
| Light/Dark Mode | Yes |
NDI Support
| NDI Control | NDI HX2, NDI HX3, High Bandwidth NDI |
| NDI Multiview | NDI HX2, NDI HX3 |
| NDI Router | Yes, follows the current active camera |
| NDI Discovery | Supported |
| NDI Access Manager | Supported |
| NDI PTZ Sensitivity | Standard (NDI), superfine (BirdDog Specific) |
Setup/Configuration
| WebUI | BirdUI for setup and firmware updates |
| Light/Dark Mode | Yes |
| API-based Camera Selection | Yes |
Serial Connections
| RS-232 | D-Sub connector (9-pin) |
| RS-422 | Phoenix connector |
Mechanical
| Joystick Type | 4D (Integrated Trigger button) |
| Keys | 37 Keys, backlit, individual contact, silicon pad |
| Toggle Dials | 4 knobs, press button, graduated, 360-degree adjustment |
| Zoom Rocket | Spring-loaded, adjustable |
| Dimensions | 14.84in x 6.96 x 4.64-inch (LxWxH including joystick) |
| Construction Material | Aluminium, OBP Ocean-Bound Plastic |
| Integrated Carry Handle | YES |
| Operating Temperature | Minus 10 degrees - 55 degrees, 14 degrees F - 130 degrees F |
| Storage Temperature | Minus 10 degrees - 55 degrees, 14 degrees F - 130 degrees F |
| Operating Humidity | 20 - 80 percent (non-condensing) |
| Storage Humidity | 0 - 90 percent (non-condensing) |
| Power Supply | PoE (802.3af), DC12V |
| Power Consumption | Less than or equal to 5W |
| Packaging Dimensions | 15.35x8.46x6.49 inch (390x215x165mm) |
