Blackmagic Design URSA Cine 17K 65 Camera with 65mm RGBW 51x24mm Sensor and 16 Stops (Body Only)
Couldn't load pickup availability
Product highlights
Product highlights
In the box
In the box
Free standard shipping
Free standard shipping
*Orders placed before 1 PM EST Mon - Thur will ship the same day. Orders placed beyond these hours will be shipped the next business day. Exclusions apply. See shipping policy
Free Local Pickup
Free Local Pickup
Please call for store stock availability. Requests made before 2:30 PM EST can be available for next-day pickup. Learn more
Blackmagic URSA Cine 17K 65 Digital Film Camera with 65mm Full Frame Sensor and Built-In 8TB Storage (Body Only)
The URSA Cine 17K 65 is a digital cinema camera designed for large format film production. With a 65mm sensor, multiple lens options, high-speed capture, and integrated 8TB storage, it is built to meet the demands of high-end production workflows. This comes with a 1 year limited manufacturer’s warranty.
65mm Format 17K Sensor
Features a 50.81mm x 23.32mm sensor with 17,520 x 8040 resolution. Provides ultra-detailed images and supports various frame sizes, ideal for cinematic storytelling.
16 Stops of Dynamic Range
Offers wide exposure latitude to handle highlights and shadows in a single shot. Helps preserve image detail and supports color correction and VFX.
Modular Lens Compatibility
Supports PL, LPL, EF, and Hasselblad HC mounts. Lens metadata is automatically captured, and lens control is available for compatible options. Offers flexibility with existing lens kits.
Up to 170 fps in 8K
Supports multiple resolutions with high-speed frame rates including 60 fps in 17K and 170 fps in 8K. Useful for motion analysis and dramatic slow-motion sequences.
8TB Internal Media Module
Includes fast internal storage to handle high-bitrate 17K RAW recording. Reduces dependency on external drives and ensures reliable data handling on set.
Dual 5-Inch Touchscreens
Includes a monitoring screen and a status/control screen, both 1920x1080 and 1500 nits brightness. Enables efficient camera operation and assistant setup.
Versatile Connectivity
Supports 10G Ethernet, WiFi, and USB-C for camera control, streaming, and cloud uploads. Also includes standard power and accessory ports for professional rigs.
RAW Recording with Proxy Options
Records Blackmagic RAW at various constant bitrate and quality settings. Simultaneous H.264 proxy recording enables quicker editing turnaround.
Post-Production Ready
Comes with DaVinci Resolve Studio and full metadata capture. Streamlines workflow from shoot to delivery with accurate scene, take, and lens data.
Imaging
| Lens Mount | Arri PL |
| Maximum Resolution | 17,520 x 8040 |
| Sensor Type | CMOS |
| Megapixels | 140.80 |
Video
| Live Streaming | Built-in |
| Recording Modes | External Mode: SDI/BNC 4096 x 2160 at 23.98/24.00/25/29.97/30.00/50/59.94/60.00 fps 1920 x 1080p at 23.98/24.00/25/29.97/30.00/50/59.94/60.00 fps 1920 x 1080i at 50/59.94/60.00 fps Internal Mode: Blackmagic RAW 12-Bit 17520 x 8040 up to 60.00 fps 16128 x 8040 15360 x 8040 14304 x 8040 12288 x 8040 9648 x 8040 17520 x 7296 12288 x 6912 12288 x 6480 11680 x 5360 up to 100 fps 10752 x 5360 8192 x 5360 12288 x 5112 up to 90 fps 8192 x 4608 8192 x 4320 8192 x 3408 up to 170 fps 5840 x 2680 5376 x 2680 4096 x 2680 4096 x 2304 4096 x 2160 4096 x 1704 |
Interface
| Wireless | Wi-Fi |
Physical
| Battery | B-Mount |
| Configuration | Core |
| Color | Black |
| Mount Type | Accessories |
Monitor
| Monitor Size | 5-inch |
- 17,520 x 8040 (17K 2.2:1 open gate)
- 16,128 x 8040 (17K 2:1)
- 15,360 x 8040 (17K 17:9)
- 14,304 x 8040 (17K 16:9)
- 17,520 x 7296 (17K 2.4:1)
- 12,288 x 8040 (12K 3:2)
- 12,288 x 6912 (12K 16:9)
- 12,288 x 6480 (12K 17:9)
- 12,288 x 5112 (12K 2.4:1)
- 9648 x 8040 (12K 6:5)
- 11,680 x 5360 (8K 2.2:1 open gate)
- 10,752 x 5360 (8K 2:1 full height)
- 8192 x 5360 (8K 3:2)
- 8192 x 4608 (8K 16:9)
- 8192 x 4320 (8K 17:9)
- 8192 x 3408 (8K 2.4:1)
- 5840 x 2680 (4K 2.2:1 open gate)
- 5376 x 2680 (4K 2:1 full height)
- 4096 x 2680 (4K 3:2)
- 4096 x 2304 (4K 16:9)
- 4096 x 2160 (4K 17:9)
- 4096 x 1704 (4K 2.4:1)
- 17K 2.2:1 open gate up to 60 fps
- 12K 2.4:1 up to 90fps
- 8K 2.2:1 open gate up to 100 fps
- 8K 2.4:1 up to 170 fps
- 2 x Monitoring Screens
- Camera Status Screen
- Blackmagic RAW Constant Bitrate 3:1
- Blackmagic RAW Constant Bitrate 5:1
- Blackmagic RAW Constant Bitrate 8:1
- Blackmagic RAW Constant Bitrate 12:1
- Blackmagic RAW Constant Bitrate 18:1
- Blackmagic RAW Constant Quality Q0
- Blackmagic RAW Constant Quality Q1
- Blackmagic RAW Constant Quality Q3
- Blackmagic RAW Constant Quality Q5
- Blackmagic RAW 3:1 - 1,700 MBPS
- Blackmagic RAW 8:1 - 637 MBPS
- Blackmagic RAW 12:1 - 425 MBPS
- Blackmagic RAW 18:1 - 283 MBPS
- Blackmagic RAW Q0 - 425 to 2,040 MBPS
- Blackmagic RAW Q1 - 255 to 1,020 MBPS
- Blackmagic RAW Q3 - 170 to 425 MBPS
- Blackmagic RAW Q5 - 127 to 319 MBPS
- 7-pin connector with plus 24V DC power output when camera is powered by plus 24V DC batteries or power supply.
- 3-pin Fischer with plus 24V DC power output when camera is powered by plus 24V DC batteries or power supply.
- B-Mount battery plate including 2-pin connector with plus 12V regulated output from camera
Blackmagic Design URSA Cine 17K 65 Camera with 65mm RGBW 51x24mm Sensor and 16 Stops
Camera Features
| Effective Sensor Size | 50.81 mm x 23.32 mm (65mm format) |
| Pixel Pitch | 2.9 microns |
| Lens Mount | PL mount. Mirrorless with URSA Cine Mount LPL Included |
| Lens Control | Lens data from compatible PL or LPL lenses and control of some PL lenses. Lens control of compatible EF lenses |
| Dynamic Range | 16 stops |
| Shooting Formats | |
| Frame Rates | Project frame rates of 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60 fps supported. Maximum sensor frame rate dependent on resolution selected |
| High Speed Frame Rates | |
| Built in ND Filters | None |
| Focus | Focus button turns on peaking, auto focus available using compatible lenses. |
| Iris Control | Iris wheel and touchscreen slider for manual iris adjustment on electronically controllable lenses, iris button for instant auto iris settings on compatible lenses so no pixel is clipped in film mode. Scene average auto exposure in video mode. |
| Screens | |
| Monitoring Screen Dimensions | 5 inch. |
| Monitoring Screen Resolution | 1920px x 1080px |
| Monitoring Screen Brightness | 1500 nits |
| Monitoring Screen Type | LCD capacitive touchscreen |
| Timecode Clock | Highly accurate timecode clock. Less than 1 frame drift every 8 hours |
Connections
| Total Video Outputs | 2 |
| SDI Rates | 1.5G, 3G, 6G, 12G |
| Analog Audio Inputs | 2 x XLR analog switchable between mic, line and AES audio. Phantom power support |
| Analog Audio Outputs | 3.5mm headphone jack |
| Reference Inputs | Tri-sync/black burst and timecode |
| USB-C Monitor Outputs | 2 x USB-C side monitor ports support URSA cine evf, pyxis monitor or displayport monitors |
| Accessories | |
| 7-pin Lemo ‘EXT’ for power out, serial communication, and run/stop | |
| 3-pin Fischer ‘RS’ for power out and run/stop. | |
| Computer Interface | 2 x USB-C side expansion ports for camera accessories. |
| Ethernet | 10Gbps RJ‑45 connector supporting 10/100/1000/10G BASE-T for SMB file sharing, web media management, blackmagic cloud uploads, camera control and streaming |
Audio
| Microphone | Integrated stereo microphone |
| Built in Speaker | Mono speaker |
Standards
| SD Video Standards | None |
| HD Video Standards | 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080i50, 1080i59.94, 1080i60 |
| Ultra HD Video Standards | 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60 |
| SDI Compliance | SMPTE 292M, SMPTE 424 Level B, SMPTE 2081-1, SMPTE 2082-1 |
| SDI Audio Sampling | 48 kHz and 24 bit |
Media
| Media | Blackmagic media module |
| Media Format | Blackmagic |
Supported Codecs
| Codecs | |
Storage Features
| Storage Type | Blackmagic media module 8TB |
| Storage Rates | Storage rates based on 24 frames per second |
| 17K - 17,520 x 8,040 | |
| Recording Formats | |
| Blackmagic RAW 3 | 1, 8:1, 12:1, 18:1, Q0, Q1, Q3 and Q5 at full sensor width or height resolutions |
| 17,520 x 8,040, 16,128 x 8,040, 15,360 x 8,040, 14,304 x 8,040 and 17,520 x 7,296 | |
| Operating Systems | Mac icon, Mac 14.0 Sonoma, Mac 15.0 Sequoia or later, Windows Icon, Windows 10 and 11 |
Physical Specifications
| Length | 11-inch |
| Weight | 8.72lb |
Power Requirements
| Power Supply | Plus 24V DC external power supply 100 - 240 AC 50/60Hz compatible with IEC C14 socket |
| Power Input | 8 pin Lemo compatible socket for external power or battery use |
| Power Output | |
Environmental Specifications
| Operating Temperature | 32 to 104-degree fahrenheit (0 to 40-degree celsius) |
| Storage Temperature | Minus 4 to 113-degree fahrenheit (minus 20 to 45-degree celsius |
| Relative Humidity | 0 to 90 percent non-condensing |
