Xenarc Technologies 12.1-inch IP65 Rugged All-Weather Sunlight Readable Panel PC
Couldn't load pickup availability
Product highlights
Product highlights
In the box
In the box
Free standard shipping
Free standard shipping
*Orders placed before 1 PM EST Mon - Thur will ship the same day. Orders placed beyond these hours will be shipped the next business day. Exclusions apply. See shipping policy
Free Local Pickup
Free Local Pickup
Please call for store stock availability. Requests made before 2:30 PM EST can be available for next-day pickup. Learn more
The Xenarc PPC1211 12.1-inch Rugged Panel PC is the most versatile and all-encompassing product in Xenarc Technologies’ lineup of products. This 16:9 1000NIT high bright panel PC is IP65 and IK08 rated and includes an optically bonded capacitive touchscreen, making it ideal for any harsh industrial environment. It utilizes Intel's automotive and industrial grade, extended temperature E3845 Quad-Core 1.91GHz CPU with a wide operating temperature range.
High-Performance Panel PC
The 12.1-inch touch panel is optically bonded to the LCD panel, eliminating the air gap between the two, increasing clarity, contrast, and durability. Furthermore, because this 12.1-inch rugged panel pc is watertight and airtight, advanced optical bonding will not allow ambient humidity to affect the clarity or viewability. The 12.1-inch rugged panel PC outperforms all other automotive grade panel PC's with a wider operating temperature range of -22 to 185-degree F and uses an IPS panel (In-Plane-Switching), which provides a wider viewing angle, consistent and accurate colors from all viewing angles, clearer images, and stable response times. A high contrast ratio of 1000:1 provides crisper images and vivid colors, even in direct sunlight. The unit was designed for those looking for a rugged, bright, all-in-one panel PC, usable in just about any environment or application.
Versatile Panel PC
The versatility of this unit extends beyond its usability in many different environments. With the included waterproof cables, the PPC1211 is IP65 on all sides. The casing of the PPC1211 is designed to be used as a stand-alone panel PC as well as a panel-mounted PC. VESA standard mounting holes on the back further provide users with a variety of mounting options. The IK08 rating makes the PPC1211 vandal-resistant and shock-resistant.
High-Grade Components
By utilizing high-grade components, this panel PC is perfect for industrial, in-car computing applications or any other application where a durable, ruggedized panel PC is required.
Connectivity
| WiFi | Yes |
| Ethernet | LAN |
General
| AC Input Power | Not Available |
Hardware
| Processor Type | Intel |
| Processor Core | 4-Core |
| Processor Speed | 1.9 GHz |
| Storage | 256GB (SSD) |
| RAM | 8GB |
Environmental
| Storage Temperature | -30°C to 85°C |
| Operating Temperature | -22 to 185-degree F (-30 to 85-degree C) |
| Operating Humidity | 5 to 95% |
| Storage Humidity | 5 to 95% |
Physical
| Weight | 7.05 lb |
| Wall Mounting | Not Available |
Video
| Video System | NTSC |
Display
| Resolution | 1280 x 800 |
| Brightness | 1000 cd/m² |
| Variable Frame Rates | Not Available |
| Panel Type | LCD |
| Bit Depth / Color Support | 8-Bit (16.7 Million Colors) |
| Viewing Angle (H x V) | 178 x 178° |
| Contrast Ratio | 1000:1 |
| Response Time | 25ms |
| Dot Pitch | Not Available |
Xenarc Technologies 12.1-inch IP65 Rugged All-Weather Sunlight Readable Panel PC
| Processor | Intel Atom E3845 Automotive Grade Processor (4 Cores, 2M Cache, 1.91Ghz) |
| Memory | 8GB RAM DDR3L-1333 |
| Internal storage | 256GB M.2 2280 Solid State Drive |
| External storage | Micro SD Card Slot x 1 |
| Operating system | Windows 10 IOT 2019 LTSC |
| Display | 12.1-Inch Automotive Grade 1280 x 800 IPS LCD |
| Display brightness | 1000 cd/m² Sunlight Readable |
| Display contrast ratio | 1000:1 |
| Display viewing angle | 178-degree Horizontal, 178-degree Vertical |
| Display response time (Tr+Tf) | 25ms (Typ.) |
| Sim card | 1.8/3.3V SIM Card |
| Cellular network support | 2G/3G/4G - GSM(B2/5), UMTS(B2/4/5), LTE-FDD(B2/4/5/12/13/17/28) |
| Bluetooth | Bluetooth 4.0 |
| WiFi | 802.11 A/B/G/N/AC (2.4G and 5G) |
| Ethernet | RJ45 10/100/1000Mbps Port x 2 |
| Navigation | GPS |
| USB | USB 3.0 x 4 |
| Serial port | RS232 Serial port x 2 |
| GPIO | 8 Bit Programable GPIO x 1 |
| CAN bus | CAN Bus x 2 |
| Audio | Built-in Waterproof Speaker x 2, Audio Input x 1, Audio Output x 1 |
| Video output | HDMI Output x 1 |
| G-Sensor | Built-in G-Sensor |
| Power switch | Built-in Power Switch x 1, Remote Power Switch x 1, ACC Shutdown Control x 1 |
| Operating voltage range | DC 9V to 36V |
| Power consumption | ≤ 40W |
| Operating temperature | -22 to 185-degree F (-30 to 85-degree C) |
| Storage temperature | -22 to 185-degree F (-30 to 85-degree C) |
| Relative humidity | 5% to 95% |
| Vibration | Operating Random Vibration Test (5-500Hz, 1.0Grms), IEC 60068-2-64 standard |
| Shock | Operating Shock Test, 10G peak acceleration (11ms duration), IEC 60068-2-27 standard |
| MTBF (Mean time between failures) | > 55,000 Hours or > 6.2 Years of continuous operation |
| Dimension | 312W x 230H x 67.2D mm |
| Weight | 7.05 lb |
